Compact Concrete Batching Plant

The plant comprises of adequate capacity gravel & sand hoppers, weighing conveyor suspended on electronic load cells, Pan type mixer unit, additive tank. Cement silo with screw conveyor, Rubber belt type charging conveyor, PLC based control panel.

Model Out Capacity Mixer Unit Batch Capacity No of BINS BINS Type Total Conveyour Weighing Type Discharge Height
YI-20 20 cu.M./hr Planetary Pan Mixer 0.40 cu.M./hr 2/4 Nos Compact 1+1 Load Cell Based 2.5 Mtr / 4 Mtr
YI-30 30 cu.M./hr Planetary Pan Mixer 0.50 cu.M./hr 2/4 Nos Compact 1+1 Load Cell Based 2.5 Mtr / 4 Mtr
YI-45 45 cu.M./hr Planetary Pan Mixer 0.75 cu.M./hr 2/4 Nos Compact 1+1 Load Cell Based 2.5 Mtr / 4 Mtr
YI-60 60 cu.M./hr Planetary Pan Mixer 1.00 cu.M./hr 2/4 Nos Compact 1+1 Load Cell Based 2.5 Mtr / 4 Mtr
