Stationary Concrete Batching Plant
The plant comprises of adequate capacity gravel & sand hoppers, weighing conveyor suspended on electronic load cells, Pan type mixer unit, additive tank. Cement silo with screw conveyor, Rubber belt type charging conveyor, PLC based control panel.
| Model | Out Capacity | Mixer Unit | Batch Capacity | No of BINS | BINS Type | Total Conveyour | Weighing Type | Discharge Height |
| YI-20 | 20 cu.M./hr | Planetary Pan Mixer | 0.40 cu.M./hr | 2/4 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr / 2.5 Mtr |
| YI-30 | 30 cu.M./hr | Planetary Pan Mixer | 0.50 cu.M./hr | 3 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr |
| YI-45 | 45 cu.M./hr | Planetary Pan Mixer | 0.75 cu.M./hr | 3 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr |
| YI-60 | 60 cu.M./hr | Planetary Pan Mixer | 1.00 cu.M./hr | 3 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr |
| YI-90 | 90 cu.M./hr | Twin Shaft Planetary | 1.50 cu.M./hr | 4 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr |
| YI-120 | 120 cu.M./hr | Twin Shaft Planetary | 2.00 cu.M./hr | 4 Nos | Inline | 2+1 | Load Cell Based | 4 Mtr |
